| 원래 장소: | 중국 |
| 브랜드 이름: | Ziitek |
| 인증: | RoHS |
| 모델 번호: | TIS580-25 |
| 최소 주문 수량: | 10KG |
|---|---|
| 가격: | 1-100USD/KG |
| 포장 세부 사항: | 1 킬로그램 /가 할 수 있습니다 |
| 배달 시간: | 3-8 근무일 |
| 지불 조건: | 티/티 |
| 공급 능력: | 10000KG/Month |
| 제품명: | 가정용 기기 부품을 위한 내습성 2.5W/MK 하나의 구성요소 실리콘 열 전도성 접착제 | 모습: | 백색 페이스트 |
|---|---|---|---|
| 예어: | 열전도성 실리콘 접착제 | 완전경화시간(d, 25℃): | 3~7일 |
| 특징: | 습기 저항 및 충격 저항 | 경도(쇼어 A): | 45 |
| 열전도도 W/(m·K): | 2.5 | TIS®580-25 시리즈의 일반적인 특성 특성 값 테스트 방법 외관 백색 페이스트 시각적 Den: | -50~250 |
| 애플리케이션: | TV 세트 및 출력 변압기 부품의 유지 관리 |
Moisture Resistance 2.5W/MK One Component Silicone Thermal Conductive Adhesive For Household Appliance Components
Company Profile
Ziitek Technology Company is dedicated to providing a comprehensive range of thermal management products and services to meet various demand scenarios. Ziitek Technology offers prompt and flexible services. Our thermal conductive materials are widely used in the fields of new energy, electronic appliances, transportation, industry, healthcare, communication, etc. Ziitek has obtained ISO9001, ISO14001 and IECQ certifications, which indicate our commitment to producing high-quality products and adopting excellent management methods. Our products comply with RoHS, REACH and UL standards, ensuring safety and reliability.
Products description
TIS®580-25 is a one-component, room-temperature curing silicone rubber with excellent adhesion, high strength and good thermal conductivity. It features superior electrical insulation, sealing performance and aging resistance, and can be used within the temperature range of -50℃ to 250℃. As a dealcoholized silicone adhesive, it cures by contacting moisture in the air and on the surface of the adherend, and is suitable for the electronics and lighting industries.
Feature
>Good thermal conductivity
>Excellent adhesion
>Superior electrical insulation
>Moisture resistance and shock resistance
>Outstanding high temperature resistance and hot water resistance
| Typical Properties of TIS®580-25 Series | ||
| Property | Value | Test Method |
| Appearance | White Paste | Visual |
| Density (g/cm3, 25℃) | 1.6 | ASTM D792 |
| Table Dry Time (min,25℃,55%RH) | ≤20 | - |
| Cure type (Single-Component) | De-alcoholized type | - |
| Viscosity @25℃ (cps) | 20000 | ASTM D1084 |
| Complete Curing Time (d, 25℃) | 3-7 | - |
| Tensile Strength (N/cm) | 8 | ASTM D412 |
| Hardness (Shore A) | 45 | ASTM D2240 |
| Cutting Strength (N/cm) | ≥2.5 | GB/T 7124 |
| Recommended Operating Temperature (°C) | -50～250 | - |
| Volume Resistivity(Ω·cm) | 2.0x1014 | ASTM D257 |
| Breakdown Voltage (V/mm) | 21000 | ASTM D149 |
| Dielectric Constant (106Hz) | 3.7 | ASTM D150 |
| Thermal Conductivity W/(m·K) | 2.5 | ASTM D5470 |
| Flame Rating | V-0 | UL 94 (E331100) |
Instructions For Use
1.Clean the surface:Prepare thesurface of theobject tobeglued or coated by cleaning it,removing rust,dust,andgrease.
2. Apply the adhesive: Unscrew the cap of the adhesive tube,use the tip of the cap to pierce the seal, and squeeze the adhesive onto the cleaned
surface for coating or pouring.
3.Curing:The coated partswilslowly formaskinwhenplaced in the air,andanyoperationsshould becompleted before thesurfaceskins over.The
curing process progresses from the surface inward,with the adhesive curing to a depth of 2-4mm within 24 hours (at room temperature and 55%
relative humidity). If the area is deeper,especially in places that are not easily exposed to air, the complete curing time wll be extended; if the
temperature is lower, the curing time will also be prolonged.
4. Note: Do not move, use, or package the treated parts until sufficient strength has been achieved.
